Features
Ultra high output and excellent low-frequency performance
Adopting a built-in low-frequency divider design, the sound quality is more natural, delicate, and pleasant to listen to.
D-class high-power amplifier module
High power voice coil long stroke direct radiation low-frequency unit
Exquisite, professional, and elegant appearance has perfect performance in any application situation
Sturdy spray painted wooden box for long-lasting durability
Sound quality characteristics: clean, powerful, and not losing elasticity.
Specifications
Acoustical specifications
Frequency Response(-3db):
50Hz-250Hz
Max SPL @ 1m:
111dB/117dB(PEAK)
Transducers
Woofer:
1 x 10" Subwoofer
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 10kΩ
Input Connectors:
1 x XLR
Power section
Total Power:
230W(RMS); 460W(MUSIC); 920W(PEAK);
Nominal Impedance (Ohm):
8Ω
Voltage range:
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)
Physical specifications
Cabinet/Case Material:
15mm Plywood
Handles:
2 × Wooden handle
Grille:
Polypropylene plastic injection molding, power coated grill
Color:
Black
Size
Dimension (W x D x H):
398 x 350 x 310mm / (15.7 x 13.8 x 12.2in)
Package Dimensions (W x D x H):
495 x 445 x 425mm / (19.5 x 17.5 x 16.7in)
Weight
Net Weight:
11 kg / 24.3 lb
Gross Weight:
12.8 kg / 28.2 lb
SUB110P Application
SUB110P Installation
SUB110P Parts
SUB110P Cases
SUB110P Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 SUB110P Datasheet | 1.0 |  | 200KB | 2024-05-17 02:08:11 |
