Features
- Compact 1U body with a stable and ultra lightweight structure.
- 3.3 inch LCD display screen for more intuitive operation.
- Excellent sound quality, equipped with high-performance audio dedicated DSP.
- Supports Dante digital audio signal transmission.
- 4x4 audio routing matrix.
- Support importing and exporting 512 order FIR filter parameters per channel.
- Modular design, simple and easy to maintain, ensuring long-term reliable performance.
- Safe and controllable, power amplifier monitoring is achieved through a single network cable, allowing for quick local diagnosis.
Specifications
RMS Stereo Power(8ohms):
4 x 650W
RMS Stereo Power(4ohms):
4 x 1100W
RMS Stereo Power(2ohms):
4 x 1870W
RMS Bridge Power(16ohms):
2 x 1300W
RMS Bridge Power(8ohms):
2 x 2200W
RMS Bridge Power(4ohms):
2 x 9520W
S/N Ratio:
72.1V
Frequency Response:
20Hz~20kHz ( ±2dB )
Power Supply Specifications:
90~260VAC,50/60Hz
Dimension (W x D x H):
483 x 45 x 370mm / (19 x 1.8 x 14.6in)
Net Weight:
9 kg / 19.8 lb
DD406NF Application
DD406NF Installation
DD406NF Parts
DD406NF Cases
DD406NF Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 DD406NF Datasheet | 1.0 |  | 200KB | 2024-05-16 18:50:13 |
