Features
- Designed with a high dynamic woofer and papercone driver for exceptional sound quality.
- Constructed with a polypropylene molding cabinet for durability.
- Point source design perfecty replay the vocal and music.
- Includes a three-channel mixer with independent EQ adjustments for instrument and microphone channels, as well as AUX/Bluetooth connectivity.
- Multiple atmosphere modes with ambient light can be adjusted to create the desired mood.
- Bluetooth 5.0 allows for stereo setup.
- Features a large capacity rechargeable battery, providing 8 hours of playtime per charge.
- Can be used as an installation or monitor speaker.
Specifications
Acoustical specifications
Frequency Response(-3db):
70Hz-15kHz
Max SPL @ 1m:
100dB/106dB(PEAK)
Dispersion (H x V):
120° x 120°
Transducers
Compression driver:
1 x 3" HF
Woofer:
1 x 8" LF
Input/Output section
Input Connectors:
2 x 1/4", 1/8", Bluetooth and Main in (1/4")
Power section
Total Power:
100W(RMS); 200W(MUSIC); 400W(PEAK);
Voltage range:
AC 110V/230V, 50Hz/60Hz
Physical specifications
Handles:
1 x Plastic handle
Grille:
Polypropylene plastic injection molding, power coated grill
Color:
Black
Size
Dimension (W x D x H):
323 x 271 x 397mm / (12.7 x 10.7 x 15.6in)
Package Dimensions (W x D x H):
380 x 330 x 460mm / (15 x 13 x 18.1in)
Weight
Net Weight:
8 kg / 17.6 lb
Gross Weight:
9.5 kg / 20.9 lb
R8P Application
R8P Installation
R8P Parts
R8P Cases
R8P Collocation
Videos
Downloads
| Filename | Version | Language | Size | Updated |
 β3 R8P Datasheet | 1.0 |  | 200KB | 2024-05-16 14:26:27 |
