TQ18 Digital Live Sound Console
TQ18 Digital Live Sound Console

TQ18

Digital Live Sound Console

TQ series adopts the fourth generation of Dual DSP digital signal processor (SIMD core), accurate 450MHz / 40 bit floating-point mathematical operation, 24bit / 48Khz high-performance ADC / DAC. 114dB typ. Dynamic range. Pay attention to every detail of your voice and show rich voice connotation.
TQ series adopts the fourth generation of Dual DSP digital signal processor (SIMD core), accurate 450MHz / 40 bit floating-point mathematical operation, 24bit / 48Khz high-performance ADC / DAC. 114dB typ. Dynamic range. Pay attention to every detail of your voice and show rich voice connotation.

Features

With the dual digital signal processors(DSP) of the fourth generation(SIMD core), precise 450MHz/40bit floating-point mathematical operation, 24bit/48KHz high performance ADC/ DAC.

 All Mic/Line input channels are configured with 48V Phantom power supply, Polarity switching ( Phase ), Noise gate (Gate ), Compressor ( Comp ), 4-band parametric frequency Equalizer ( PEQ )/including high shelf ölter( HSF ), low shelf filter( LSF ), high pass filter( HPF ), low pass filter( LPF ).

 All output channels are configured with Delay, Compressor ( Comp ), graphic frequency Equalizer ( GEQ ), 4-band parametric frequency Equalizer ( PEQ ) /including high shelf filter ( HSF ),low shelf filter ( LSF ), high pass filter ( HPF ), low pass filter( LPF ).

 Configuration 4 professional DSP effectors ( FX ), 6 effect types: Chorus, Echo, Flanger, Pitch-Shift, Reverb, ping-pong ( Stereo Delay ), totally over one hundred types of effect preset.

 8~16 DCA volume groups and 8 MUTE groups that can be easily operated with one key.

 The color 1.44-inch TFT navigation screen .

 Voltage range (85Vac~ 240Vac),

TQ-18 mixer provides Wireless WiFi hot spot, the IOS device ( Apple iPad etc. ) can be wirelessly connected to the mixer for remote controlled operation.


Specifications

TQ18 Application

    TQ18 Installation

      TQ18 Parts

        TQ18 Cases

          TQ18 Collocation

            Videos

              Downloads

              FilenameVersionLanguageSizeUpdated
              TQ18β3 TQ18 Datasheet 1.0TQ18  200KB 2024-03-19 18:51:01
              β3_TQ18_Digital_Live_Sound_Console_Chinese_Manualβ3_TQ18_Digital_Live_Sound_Console_Chinese_Manual 1β3_TQ18_Digital_Live_Sound_Console_Chinese_Manual  572KB 2022-05-09 16:38:24
              β3_TQ18_Digital_Live_Sound_Console_English_Manualβ3_TQ18_Digital_Live_Sound_Console_English_Manual 1β3_TQ18_Digital_Live_Sound_Console_English_Manual  5602KB 2022-05-09 16:39:05
