Features
◇ Two-unit two-way full-band, high sound pressure and high sensitivity speaker
◇ An 8-inch high-power woofer
◇ A 1 inch PEI polymer diaphragm treble compression driver
◇ 7×M8 bracket hoisting point
Specifications
Acoustical specifications
Frequency Response(-3db):
80Hz-20kHz
Max SPL @ 1m:
113dB/119dB(PEAK)
Dispersion (H x V):
90° x 90°
Transducers
Compression driver:
1 x 1.4" HF
Woofer:
1 x 8" LF
Input/Output section
Input Connectors:
2 x XLR
Power section
Total Power:
140W(RMS); 280W(MUSIC); 560W(PEAK);
Nominal Impedance (Ohm):
8Ω
Cooling:
Cooling fan
Power consumption(static):
11W
Power consumption(rated):
180W
Voltage range:
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)
Physical specifications
Cabinet/Case Material:
15mm Plywood
Hardware:
2 x M8 Bracket lifting point
Grille:
Cabinet coated by Polyurethane paint; grille is powder coated
Color:
Black
Size
Dimension (W x D x H):
280 x 262 x 380mm / (11 x 10.3 x 15in)
Package Dimensions (W x D x H):
340 x 320 x 460mm / (13.4 x 12.6 x 18.1in)
Weight
Net Weight:
9.5 kg / 20.9 lb
Gross Weight:
10.5 kg / 23.1 lb
SAK208Ta Application
SAK208Ta Installation
SAK208Ta Parts
SAK208Ta Cases
SAK208Ta Collocation
Videos
Downloads
Filename | Version | Language | Size | Updated |
β3 SAK208Ta Datasheet | 1.0 | 200KB | 2024-05-01 09:28:50 |
