Features
- 2 x balanced XLR or 6.5mm line level inputs
- Selectable voltage binding post outputs
- Front panel volume controls for each channel
- LED signal, peak and power indicators
- Voltage outputs 50V, 70V, 100V - bridge mode 100V, 140V, 200V
- Protection for short circuit, over load, over heat
- Variable speed fans
Specifications
Rated Power | 2 x 625W (RMS) Dual Channel, 1250W (Bridged) |
| THD (@1kHz) | <0.5% (Normal working condition) |
| Amplifier Type | |
| S/N Ratio | 100dB |
| Damping Factor | |
| Frequency Response (+0/-0.25dB) | 50Hz-16kHz |
| Input Sensitivity | 1V |
| Input Impedance | 20kΩ Balanced, 10kΩ Unbalanced |
| Input connector | XLR/6.5mm socket |
| Output Connector | Crew Terminal |
| Power Supply | 220V/230V 50/60H, 600VA |
| Cooling | |
| Dimensions (W x D x H) | 483mm (19”) x 376mm (14.8”) x 88mm (3.5”) |
| Packing Dimension (W x D x H) | |
| Net Weight | 22kg (48.5lb) |
| Gross Weight | 23kg (50.7lb) |
