SAK4.1

4" Two Way Full Range Speaker

The SAK4.1 is an excellent sound quality, versatile, easy to install, lightweight and compact speaker that is the perfect combination of sound versatility, ease of use and aesthetics. The high frequency is clear and delicate, the mid frequency is round and full, and the low frequency is elastic. The box adopts octagonal design, which makes the standing wave in the box small, the distortion is extremely low, and the timbre is pure. It is especially suitable for the occasions that require a small box, easy installation and high requirements for sound quality. Whether it's installing a compact sound reinforcement system in a conference room, classroom, church or providing fill for larger venues.


Features

◇The box is made of domestic laminate, and the surface is made of paint

◇Various installation methods and corresponding optional installation accessories, suitable for installation in various places

◇The sound quality of the speaker: clear, full, and heavy

Specifications

Acoustical specifications
Frequency Response(-3db):
100Hz-20kHz
Max SPL @ 1m:
103dB/109dB(PEAK)
Dispersion (H x V):
150° x 150°
Transducers
Compression driver:
1 x 1" HF
Woofer:
1 x 4" LF
Input/Output section
Input Connectors:
Terminals
Sensitivity (1W @ 1m):
87dB
Power section
Total Power:
40W(RMS); 80W(MUSIC); 160W(PEAK);
Nominal Impedance (Ohm):
Physical specifications
Cabinet/Case Material:
15mm Plywood
Grille:
Cabinet coated by Polyurethane paint; grille is powder coated
Color:
Black
Size
Dimension (W x D x H):
144 x 146 x 214mm / (5.7 x 5.7 x 8.4in)
Package Dimensions (W x D x H):
200 x 200 x 281mm / (7.9 x 7.9 x 11.1in)
Weight
Net Weight:
3 kg / 6.6 lb
Gross Weight:
4 kg / 8.8 lb

SAK4.1 Application

    SAK4.1 Installation

      SAK4.1 Parts

        SAK4.1 Cases

          SAK4.1 Collocation

            Videos

              Downloads

              FilenameVersionLanguageSizeUpdated
              SAK4.1β3 SAK4.1 Datasheet 1.0SAK4.1  200KB 2022-05-19 14:26:53
