SAK212 - 12" Two Way Full Range Speaker

SAK212

12" Two Way Full Range Speaker

SAK212 is a two-unit two-way full-range professional speaker. Consists of a 12-inch Clothedge woofer and a 44-pin titanium diaphragm compression driver. Great dynamics, high sensitivity, clear mid and high frequencies, and good low frequency dynamics.The box body is made of laminate, with a wooden wedge structure, and the surface polyurethane paint has strong anti-wear ability. The tensile strength of the box itself reaches 4500N. The hoisting method of the speaker adopts a special hoisting form to bear the tensile force of 3000N at a single point, reaching a hoisting safety factor higher than 7 times. The surface mesh of the speaker is made of Q235, and the surface is sprayed with powder, so that the surface mesh not only has high strength, but also has good resistance to salt spray, and its ability to resist salt spray (5% sodium hydroxide) Up to 96 hours, in actual use, it can be used continuously for 5 years without rusting without damage.


Features

◇A 44-core titanium diaphragm tweeter compression driver

◇A 12-inch Cloth edge woofer

◇M10 lifting point

◇Mainly used in conference rooms, multi-purpose halls, churches, auditoriums and main and fill sound in performance venues

Specifications

Acoustical specifications
Frequency Response(-3db):
50Hz-20kHz
Max SPL @ 1m:
124dB/130dB(PEAK)
Dispersion (H x V):
90° x 60°
Transducers
Compression driver:
1 x 44mm HF
Woofer:
1 x 12" LF
Input/Output section
Input Connectors:
2 x NL4
Sensitivity (1W @ 1m):
97dB
Power section
Total Power:
450W(RMS); 900W(MUSIC); 1800W(PEAK);
Nominal Impedance (Ohm):
Physical specifications
Cabinet/Case Material:
15mm Plywood
Grille:
Cabinet coated by Polyurethane paint; grille is powder coated
Color:
Black
Size
Dimension (W x D x H):
350 x 380 x 600mm / (13.8 x 15 x 23.6in)
Package Dimensions (W x D x H):
495 x 465 x 725mm / (19.5 x 18.3 x 28.5in)
Weight
Net Weight:
21.5 kg / 47.4 lb
Gross Weight:
23.5 kg / 51.8 lb
