MS4

Two Way Full Range Column Speaker

MS4 is a compact and elegant passive column speaker designed and manufactured to provide outstanding projection as well as uniform coverage and sound quality. Composed of 4 x 2.75" full-range drivers, MS4 adopts a symmetrical design in its driver placements to provide more control in the speaker's vertical coverage. Utilizing an unique joinery that eliminates the use of screws in the construction of the enclosure, MS4 offers a stylish appearance while keeping its low-profile.


Features

  • High quality birch plywood cabinet
  • Built-in 70V/100V transformer, together with 8Ω direct capability

  • Speech/Music mode available

  • Multiple mounting available
  • Suited for multifunctional halls, schools, places of worship, auditoriums, conference rooms, and other performance venues
  • Available in black/white


Specifications

Acoustical specifications
Frequency Response(-3db):
220Hz-20kHz
Max SPL @ 1m:
115dB;MUSIC:113dB
Dispersion (H x V):
140° x 40°
Transducers
Transducer Driver:
4 x 2.75" Full Range Speaker
Input/Output section
Sensitivity (1W @ 1m):
83dB
Power section
Total Power:
30W
Nominal Impedance (Ohm):
8 Ω
Physical specifications
Color:
White
Size
Dimension (W x D x H):
104 x 130 x 333mm / (4.1 x 5.1 x 13.1in)
Package Dimensions (W x D x H):
185 x 160 x 398mm / (7.3 x 6.3 x 15.7in)
Weight
Net Weight:
2.6 kg / 5.7 lb
Gross Weight:
3.0 kg / 6.6 lb
