The Beta Three® CS series is specifically designed to provide state-of-the-art cinema solutions developed and manufactured using the latest technology. The CS series comprises of two-way, three-way, and four-way screen channel systems as well as surrounds and subwoofers. This series of professional cinema sound systems offer superior-quality audio and extraordinary reliability, just so to ensure every audience in the room receives the complete sound experience intended by the filmmaker.

CSR10 10" 2-way Cinema Speaker

CSR10

10" 2-way Cinema Speaker

The Beta Three® CSR10 Cinema Series loudspeaker is a surround two-way mid/high horn loudspeaker designed and engineered to meet the demanding requirements within Digital Cinema installations where high quality music and vocal reproduction is essential.


Features

  • 10'' two-way full range speaker, consisting of 1x10''LF and 1x1.7'' HF.
  • Frequency range 60Hz - 16kHz (-3dB)
  • 126dB High SPL, 94dB high sensitivity.
  • Computer simulating design provide very good Frequency response and phase feature.
  • 4 x M6 on the back, 1 x M8 on each side

Specifications

Acoustical specifications
Frequency Response(-3db):
60Hz-20kHz
Max SPL @ 1m:
120dB/126dB(PEAK)
Dispersion (H x V):
55° x 55°
Transducers
Compression driver:
1 x 44mm HF
Woofer:
1 x 10" LF
Input/Output section
Input Connectors:
Spring clip
Sensitivity (1W @ 1m):
94dB
Processor section
Crossover frequencies:
1.6kHz
Power section
Total Power:
200W(RMS); 400W(MUSIC); 800W(PEAK);
Nominal Impedance (Ohm):
Physical specifications
Cabinet/Case Material:
ladder-shaped. MDF
Hardware:
4 x M6 lifting point on the back, 1 x M8 lifting point at each side
Grille:
surface of cabinet with Black polyurethane, spray surface of grill with black mesh
Color:
Black
Size
Dimension (W x D x H):
556 x 253 x 455mm / (21.9 x 10 x 17.9in)
Package Dimensions (W x D x H):
545 x 345 x 660mm / (21.5 x 13.6 x 26in)
Weight
Net Weight:
15 kg / 33.1 lb
Gross Weight:
17.6 kg / 38.8 lb
