TW8a

8" Two Way Full Range Active Speaker

Portable and installed active loudspeakers used in applications including sound reinforcement in Front of House and Foldback applications in house of worship, events, clubs, rehearsal etc. Both active and passive version deliver extraordinary performance at unmatched value.


Features

  • High output SPL and sensitivity
  • Built-in high power amplifier module with DSP
  • Master volume control
  • XLR input and output connectors
  • Smart sound quality adjustment
  • Integrated pole mount adaptor at bottom
  • Portable system (stand), or permanent installation (wall, ceiling, under balcony)
  • Suitable for use as a main system with or without sub speaker augmentation
  • Powder coated protective grill
  • Durable Polyurethane textured base paint

Specifications

Acoustical specifications
Frequency Response(-3db):
85Hz-18kHz
Max SPL @ 1m:
112dB/118dB(PEAK)
Dispersion (H x V):
130° x 140°
Transducers
Compression driver:
1 x 1" HF
Woofer:
1 x 8" LF
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 10kΩ
Input Connectors:
XL/TRS,RCA,Mixed male output
Power section
Total Power:
450W(RMS)
Nominal Impedance (Ohm):
Voltage range:
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
225 x 270 x 408mm / (8.9 x 10.6 x 16.1in)
Package Dimensions (W x D x H):
345 x 305 x 495mm / (13.6 x 12 x 19.5in)
Weight
Net Weight:
10 kg / 22 lb
Gross Weight:
11 kg / 24.3 lb

TW8a Application

    TW8a Installation

      TW8a Parts

        TW8a Cases

          TW8a Collocation

            Videos

              Downloads

              FilenameVersionLanguageSizeUpdated
              β3_TW8a_Plastic_Speaker_Manualβ3_TW8a_Plastic_Speaker_Manual 1β3_TW8a_Plastic_Speaker_Manual  594.45KB 2018-07-12 02:25:39
