TW215a

Dual 15" Two Way Full Range Active Speaker

Portable and installed active loudspeakers used in applications including sound reinforcement in Front of House and Foldback applications in house of worship, events, clubs, rehearsal etc. Both active and passive version deliver extraordinary performance at unmatched value.


Features

  • High output SPL and sensitivity
  • Built-in high power amplifier module with DSP
  • Master volume control
  • XLR input and output connectors
  • Smart sound quality adjustment
  • Integrated pole mount adaptor at bottom
  • Portable system (stand), or permanent installation (wall, ceiling, under balcony)
  • Suitable for use as a main system with or without sub speaker augmentation
  • Powder coated protective grill
  • Durable Polyurethane textured base paint

Specifications

Acoustical specifications
Frequency Response(-3db):
45Hz-18kHz
Max SPL @ 1m:
128dB/134dB(PEAK)
Dispersion (H x V):
50° x 55°
Transducers
Compression driver:
1 x 3" HF
Woofer:
2 x 15" LF
Input/Output section
Input signal:
Balanced 20kΩ, Unbalanced 2kΩ
Input Connectors:
Input: 2 x Combo(one with Mic/Line switch),Output: 3 x XLR
Power section
Total Power:
1500W(RMS)
Nominal Impedance (Ohm):
Voltage range:
AC 220V-240V~, 50/60Hz (or AC 110V-120V~, 50/60Hz)
Standard compliance
CE marking:
Yes
Physical specifications
Color:
Black
Size
Dimension (W x D x H):
520 x 520 x 1090mm / (20.5 x 20.5 x 42.9in)
Package Dimensions (W x D x H):
650 x 650 x 1240mm / (25.6 x 25.6 x 48.8in)
Weight
Net Weight:
53 kg / 116.8 lb
Gross Weight:
60 kg / 132.3 lb

TW215a Application

    TW215a Installation

      TW215a Parts

        TW215a Cases

          TW215a Collocation

            Videos

              Downloads

              FilenameVersionLanguageSizeUpdated
              β3_TW215a(100V-120V)_PA_English_Manualβ3_TW215a(100V-120V)_PA_English_Manual 1β3_TW215a(100V-120V)_PA_English_Manual  802.14KB 2018-07-12 02:25:39
              β3_TW215a(220V-240V)_PA_English_Manualβ3_TW215a(220V-240V)_PA_English_Manual 1β3_TW215a(220V-240V)_PA_English_Manual  802.7KB 2018-07-12 02:25:39
              β3_TW215a_PA_Chinese_Manualβ3_TW215a_PA_Chinese_Manual 1β3_TW215a_PA_Chinese_Manual  1002.44KB 2018-07-12 02:25:39
